Standard Silicone Gel-Film® ☰ Quick Links × Quick Links E-Store Request Quote Request Sample Contact Technical Support Product Selection Wizard Calculate Number Of Devices/Carrier Gel-Pak Brochure Gel-Film® Gel-Pak’s Gel-Film®, based on our proprietary silicone Gel or silicone-free, static dissipative Vertec® technologies, is designed to support, protect and handle fragile substrates used in the Semiconductor, Medical, and Electronics industries. Gel-Films are offered in a variety of constructions including: WF, WF-A, WPV, WPV-A PF, PPV DGL Request a Quote Request a Sample Gel-Film® Details WF/WPV Series PF/PPV Series DGL Series Datasheets Resources Gel-Film® Standard Sizes Ranges from 2”x 2” up to 7” x 7” or round sheets. Custom shapes, sizes and rolls also available. Elastomer Traditional silicone Gel (WF, PF, DGL Series) or silicone-free, static dissipative Vertec® (WPV, PPV Series) Elastomer Thickness See product tabs for details Traditional Gel Tack Levels Silicone-Free, ESD Vertec Tack Levels WF and WPV film is Gel or Vertec elastomer bonded to a metalized polyester substrate material which gives a light gray appearance. WF and WPV is available with optional Pressure Sensitive Adhesive (PSA) backings which enables mounting of the film to any flat working surface (i.e. fixture, table). WF-A and WPV-A film with a PSA backing is used for a wide assortment of applications where a tacky surface is required to hold a device during processing and/or assembly, such as: Disk Drive Row Bar Lapping Process Handling Fixtures Flex circuit laser cutting Sealing Gaskets Kitting of small components High Temperature Processes (up to 150°C) WF and WPV film alone (without PSA) also has a variety of uses where the elastomer surface is mounted directly to the device, such as: Surface Protection Polishing Optics Scribe and Break cover sheet Flat panel display cover Support for handling fragile wafers Wafer Backgrinding High Temperature Processes (up to 150°C) The WF/WPV Film comes in several retention levels and elastomer thickness combinations. Retention Level Elastomer Thickness 1.5 mil 6.0 mil 17.0 mil X0 X X4 X X X8 X X EH02 X EH04 X EH06 X Elastomer Thickness Combination ChartCustom versions of the WF film can be manufactured upon request. The PF and PPV Film is similar to the WF/WPV product except the elastomer material is not bonded to its clear polyester substrate. This allows the elastomer material to be easily removed from the polyester backing, otherwise known as “Free-Gel”. The PF and PPV film is optically clear. The more commonly used version of “Free-Gel” is the purified silicone Gel version referred to as DGL Film. PF/PPV film is available in standard square, rectangular, and round sheet sizes or can be custom cut to any shape and size per the customer’s specific requirements. This product is typically used for unique process applications where a double-sided elastomer film material is required, such as: Process Handling Fixtures requiring optically clear film Finger Print Recognition High Temperature Processes (up to 220°C) *Silicone Gel version only The PF/PPV Film comes in several retention levels and Gel thickness combinations. Retention Level Elastomer Thickness 1.5 mil 6.5 mil 17.0 mil XT X X X0 X X X4 X X X XT X X EH02 X X EH04 X X EH06 X X Elastomer Thickness Combination ChartCustom versions of the PF/PPV film can be manufactured upon request. DGL film is a Process B version of the PF “Free-Gel” film. The optically clear purified Free-Gel is laminated onto a flexible polyethylene backing with an easy to remove polycarbonate material used as the coversheet. For applications where a double-sided Gel material is required, DGL is typically the Gel-Film® product of choice. The Free-Gel can be exposed up to 220°C for long duration. DGL film is available in standard sizes or can be sold in any custom shape and sizes per your specific requirements. DGL film is available in standard sizes or can be sold in any custom shape and sizes per your specific requirements. DGL film is used for a wide number of applications where either ultraclean or high temperature film or tapes are required, such as: Vacuum Coating Processes Scribe & Break Coversheet High Temperature in-process handling Temporary Wafer Bonding Disk Drive Lapping The DGL Gel-Film® comes in several retention levels and Gel thickness combinations. Custom versions of the DGL film can be manufactured upon request. Refer to the DGL Film Technical Datasheet for more detailed information regarding the actual thickness of the film products. Retention Level Gel Thickness 1.5 mil 6.5 mil 17.0 mil XT X X X0 X X X4 X X X X8 X X Gel Thickness Combination Chart Index #TD-001 DescriptionDGL Film Outgassing AvailabilityContact Factory Index #TD-002 DescriptionWF/PF Film Outgassing AvailabilityContact Factory Index #TD-004 DescriptionGel Composition (FT-IR) AvailabilityContact Factory Index #TD-005 DescriptionGel Ionic Properties AvailabilityContact Factory Index #TD-006 DescriptionRoHS Test Report AvailabilityDownload Index #TD-007 DescriptionGel Optical Properties AvailabilityDownload Index #TD-012 DescriptionGEL Long-Term Aging Study AvailabilityDownload Index #TD-016 DescriptionWF/LF (-A) Gel-Film Product Information AvailabilityDownload Index #TD-017 DescriptionESD Properties AvailabilityDownload Index #TD-018 DescriptionBox/Tray Material Temperature Properties AvailabilityContact Factory Index #TD-021 DescriptionPF Gel-Film Product Information AvailabilityDownload Index #TD-029 DescriptionREACH Test Report AvailabilityDownload Index #TD-032 DescriptionGel-Film Outgassing/Total Mass Loss AvailabilityContact Factory Index #TD-033 DescriptionDGL Gel-Film Product Specification AvailabilityDownload Index #TD-039 DescriptionVertec Outgassing AvailabilityContact Factory Index #TD-041 DescriptionBiocompatibility test (Cytotoxicity) AvailabilityDownload Index #TD-047 DescriptionVertec TPE Product SDS AvailabilityContact Factory Index #TD-049 DescriptionStandard Gel Products SDS AvailabilityContact Factory Index #TD-051 DescriptionVertec_vs_Silicone FTIR AvailabilityContact Factory Index #TD-062 DescriptionVertec_PU_FTIR AvailabilityContact Factory Index #TD-063 DescriptionVertec Polyurethane Elastomer SDS AvailabilityContact Factory Index #TD-065 DescriptionVertec WFV E-Film Info AvailabilityDownload Index #TD-068 DescriptionVertec EH07 Outgassing AvailabilityContact Factory Index #TD-070 DescriptionVertec FM71 Biocompatibility AvailabilityDownload Index #TD-071 DescriptionVertec PolyU Biocompatibility AvailabilityDownload Index #TD-072 DescriptionVertec WF-A Products SDS AvailabilityDownload Index #TD-080 DescriptionTextured Vertec Film (Preliminary) AvailabilityDownload Index #TD-086 DescriptionPFV TPE-FILM Information AvailabilityDownload Index #TD-087 DescriptionVertec EH02 & EH04 Outgassing AvailabilityContact Factory Index #TD-095 Description Elastomer Tack Chart AvailabilityDownload Index #TD-098 DescriptionVertec FK79 TPE Biocompatibility AvailabilityDownload Index #TD-099 DescriptionPPV VERTEC Polyurethane Film AvailabilityDownload Index #TD-100 DescriptionWPV PU Film Information AvailabilityDownload Index #TD-102 DescriptionTD-102B GP TPU FILM SDS AvailabilityContact Factory Index #TD-105 Description TXF Film Outgas AvailabilityContact Factory Index #TD-116 DescriptionVertec-PU Long-Term Aging Study AvailabilityDownload Elastomer Technology Overview Product Selection Wizard Gel-Film Video Gel-Film® Part Number Catalog Coming Soon! Quick Turn Gel-Film® Parts The following Gel-Film® parts are available for purchase online in limited quantities with a 10-day lead time. For larger quantities, or for parts not listed below, please contact us for a quote. Showing 1 – 5 of 46 results Showing all 46 results Showing the single result No results found Sort by Price low to high Sort by Popularity Sort by Rating Sort by Price low to high Sort by Price high to low Sort by Newness Sort by Name A - Z Sort by Name Z - A Filters Sort results Reset Apply ImageNameDescriptionPurchase now PF-40×40-0170-X8Dimensions:4.0" x 4.0"Gel Thickness (Mils):17.0Minimum Order Quantity:50Gel Tack Level:X8…Purchase nowWF-40×40-0060-X0Dimensions:4.0" x 4.0"Gel Thickness (Mils):6.0Minimum Order Quantity:100Gel Tack Level:X0…Purchase nowWF-40×40-0015-X4Dimensions:4.0" x 4.0"Gel Thickness (Mils):1.5Minimum Order Quantity:100Gel Tack Level:X4 WARNING:…Purchase nowWF-40×40-0060-X4Dimensions:4.0" x 4.0"Gel Thickness (Mils):6.0Minimum Order Quantity:100Gel Tack Level:X4…Purchase nowWF-40×40-0060-X8Dimensions:4.0" x 4.0"Gel Thickness (Mils):6.0Minimum Order Quantity:100Gel Tack Level:X8…Purchase now 12…10 Please visit Cleanroom Tape for additional information. Visit Now!
